Trident-IMM

Hash House Trident-IMM is a series of immersion cooling containers engineered for high-efficiency thermal management and scalable deployment, with flexible customization to fit your specific requirements.

Premier Design

01.

Plug-and-Play Effciency

Trident series containers are is housed in a standard ship-class certified 40/45-foot container, eliminating the need for external cooling sources or customized logistics requirements. These features enable quick and hassle-free deployment, scalability, and migration that lead to significant time and cost savings.

02.

All-in-One Design

Trident series containers integrate integrates essential components including the tank, smart PDU, power distribution system, and security system into a single comprehensive unit. This streamlined design ensures optimal performance and simplifies maintenance procedures.

03.

MicroBT Immersion Series Certification

In collaboration with MicroBT, Trident-IMM is the first certified ICM-DC specifically customized for the MicroBT Mx6 series and thus offers the following advantages:

• A purposefully designed tank reduces coolant requirements, driving down costs while enhancing server cooling efficiency.

• The product supports MicroBT Mx6 series overclocking by up to 8.6KW, boosting computational power by 30%.

• Every inch of the space is optimized for both operational and maintenance purposes.

04.

Customized Coolant (Synos™ Max21 Immersion Coolant)

Our specialized coolant-a synthetic, single-phase immersion fluid designed for high-performance computing (HPC) applications that is MicroBT certified and meets factory warranty requirements. It has high cooling efficiency, fluidity and excellent thermodynamic properties to reduce energy consumption. Safe and easy to use, it contributes to a safer working environment. Synos™ Max21 immersion coolant is both cost-effective and offers exceptional performance.

05.

ZERO Water Consumption

Trident128-ID1200 provides cooling option flexibility, offering either an air ­cooled system with dry coolers or a closed-loop cooling tower system based on site requirements. Its air-cooled system allows Trident128-ID1200 to achieve zero water consumption with minimal maintenance required. Even with a closed-loop tower cooling system, water consumption remains extremely low without the need for special water treatment.

06.

Smart Noise Reduction

Equipped with smart frequency conversion fans and pumps, Trident series containers ensure efficient heat dissipation while dynamically reducing machine ­generated noise levels with indoor maintained below 45 decibels.

07.

Premium quality

All important components sourced from trusted brands and certified with UL standards for safety and reliability.

08.

Customizable design

Customizable design approach allows us to tailor every aspect of the design and production process, ensuring that the final product aligns perfectly with your unique needs and expectations.

Trident-IMM

Trident128-ID1200

Trident128-IE1200

Trident160-ID1100

Overview

Dimension

45HQ 13,716 x 2,438 x 2,896 mm (LxWxH)

40HQ 12,192 x 2,438 x 2,896 mm (LxWxH)

40HQ 12,192 x 2,438 x 2,896 mm (LxWxH)

Compatible Coolant

Synos™ Max21 Immersion Coolant, Shell S3X

Est. Shipping Weight

38,616lb(17,516kg)

41,204lb(18,690kg)

33,070lb(15,000kg)

Miner Capacity

Whatsminer

128

128

-

Antminer(S19/S21)

-

-

192

Antminer(S21Imm)

-

-

160

Power

Max. Power Load

1,200kW

1,200kW

1,100kW

Smart PDU Quantity

8

8

8

Cooling

Cooling Type

Dry Cooler

Evaporative Cooling Tower

Dry Cooler

Environment

Ambient Temperature

-35~45℃/-31~113℉

-35~45℃/-31~113℉

-35~45℃/-31~113℉

After Sales

Warranty

1 Year

1 Year

1 Year

Default

Specifications

Globally compatible

3-Phase 380V–480V electrical system compatible with global standards required

01

Optimized PUE&WUE

At 45°C, with zero water consumption and PUE as low as 1.06 — driving high efficiency (based on standard ASIC operation mode)

02

Efficiency and Reliability

Strategic partnerships with global leaders like Wilo, Kelvion, Guntner, and Norak enable us to develop custom solutions optimized for efficiency, reliability, and lifespan

03

Intelligent Control System

With the Siemens PLC system, users can seamlessly monitor machine status, ensuring maximum protection and optimized system performance

04

Quick Depoly

Highly prefabricated solution allows for rapid on-site installation and deployment immediately after delivery.

05

Enhanced

Options

Centralized Intelligence

Smart group control and remote operation enable efficient multi-unit management and rapid power response.

01

User-friendly

Air-conditioned modules enhance the working environment and improve operational comfort for maintenance personnel

02

Built for Global Standards

We offer highly adaptable solutions that are certifiable to UL, CSA, CE, DOE, and ASME standards, and can be custom-engineered to meet NFPA, ISO, and ANSI requirements, meeting diverse regulatory needs across global markets.

03

Fully Customized

Delivering plug-and-play solutions customized for each project's unique requirements

04
